Rated Capacity: 1/2/3/5/10/20t
Accuracy Class: C3
Rated Output: 2.0±0.1mV/V
Total error: ±0.02%F.S
Creep(30min): ±0.02%F.S
Input Resistance: 760±10Ω
Output Resistance: 701±10Ω
Operating Temperature: -10~+40℃
Safe Overload: 150%F.S
Destructive Load: 200%F.S
Excitation Recommend: 4~12VDC Max:15VDC
Cable Length: 0.5~2m 4 wires with shield
Exc+(red) Exc-(black) Sig+(green) Sig-(white)
Construction: Alloy steel,IP67
Application for: Crane,packing scale,tension etc.
