Rated Capacity: 10/20/25/30/40t
Accuracy Class: D1
Rated Output: 3.0±0.006mV/V
Total error: ±0.05%F.S
Creep(30min): ±0.05%F.S
Input Resistance: 385±10Ω
Output Resistance: 351±2Ω
Operating Temperature: -10~+40℃
Safe Overload: 150%F.S
Destructive Load: 200%F.S
Excitation Recommend: 4~12VDC Max:15VDC
Cable Length: 12m 4 wires with shield
Exc+(red) Exc-(black) Sig+(green) Sig-(white)
Construction: Alloy Steel,IP67
Application for: hopper scale,silo scale,testing machine etc.
